Product Details
Place of Origin: Hebei China
Brand Name: SENSU
Certification: IATF 16949
Model Number: toyota
Payment & Shipping Terms
Minimum Order Quantity: 500 PCS
Packaging Details: Plastic bag, Box, Cartons, Plallet
Delivery Time: 25-30 Days
Payment Terms: L/C, T/T
Supply Ability: 80000/PCS/MON
Material: |
SS304 |
Color: |
Silver |
Port Of Loading: |
Tianjin(nearby), Qingdao, Shanghai, Ningbo, Guangzhou |
Shipment: |
By Sea/By Air/By Parcel |
Material: |
SS304 |
Color: |
Silver |
Port Of Loading: |
Tianjin(nearby), Qingdao, Shanghai, Ningbo, Guangzhou |
Shipment: |
By Sea/By Air/By Parcel |
| Product Name: | 2" 180 U Mandrel Bend Pipe Tubing Tube 304 Stainless | Material: | 304 Stainless Steel |
|---|---|---|---|
| Packing: | Bubble Bag Into Wooden Case | OEM: | Available |
| Thickness: | 1.2mm | Angle: | 180 Degree |
| Advantage: | Wrinkle Free | Size: | 2" |
| Type: | Mandrel Bend | MOQ: | 1PC |
| High Light: |
2 Inch 180 Degree Exhaust Elbow,1.2mm 180 Degree Exhaust Elbow,SS304 180 Degree Exhaust Elbow |
||
2" 180 U Mandrel Bend Pipe Tubing Tube 304 Stainless
YP exhaust pipes are available for various applications. Available in diameters ranging from 2.5 In. to 4 Inch. Angle from 0 degree to 180 degree, our mandrel bending machines ensure smooth bending, no wrinkle and crimping. YP mandrel bends have the tightest bend radius on the market.They have been specifically designed to avoid the issue of wrinkling along the inside of pipes and tubing, during their manufacturing process with our up to date mandrel bending machines. Mandrel bending is a method where a steel rod is inserted into the tubing as it is bent. This technique perfects the tube bend without wrinkling or breaking it at the bending point. As we know, mandrel bending process is one of the most accurate and cost-effective metal forming processes,when an exhaust or downpipe is produced with mandrel bends, the steel is allowed to stretch on the outside of the bend and compress on the inside of the bend, maintaining the nominal pipe diameter. In Yunpeng, with our advanced bending machines, we produce variety of bend pipe at different angles and length, with wrinkle free and anti-rust. Many details as below. If you have any bend pipe demand, pls feel free to contact Yunpeng, your inquiry will be replied within 24hours.
Mandrel bends introduction:
| Name | 2" 180 U Mandrel Bend Pipe Tubing Tube 304 Stainless |
| Application | Car accessories |
| Shape | Round head |
| Material Choice |
Different materials, such as carbon steel, aluminum, stainless steel, titanium alloy, aluminum plated pipe, galvanized pipe are available in Yunpeng.
|
| Size and Diameter |
we can also make the pipe diameter from 1/2 to 6 inches Bending radius minimum 1.0D, others like 1.2D, 1.3D,1.5D,2Detc. The length of the foot we can make is 152mm |
| Wall thickness |
Stainless steel commonly used wall thickness is 1.5,1.25, liner muffler is 1.0,1.2; Aluminum is from 1.2-2.5mm, elbow is usually 1.5-2.5mm. |
| Angle | From 0 degrees to 180 degrees, like 15°,30°,45°,60°,75°,90°,135°,180° |
| Surface treatment | We can do raw,polishing,brush, antirustoil, plating including zinc plating,chrome plating, anodize,spray paint,powder coating. |
| Aperture processing | We can do beaded rolled,beaded ends,swaged,expanding,cut |
| Welding | we use the tig welding and mig weiding |
| Feature |
1.Constructed using 100% aluminum and stainless steel 2.Variety radius,many applications; 3.Many tube diameters and lengths; 4.Easy Installation; 5.Smooth, anti-rust. |
